Indoor LED Display Modules Featuring Adjustable Magnet Height for Improved Screen Flatness and Enhanced Visual Performance
商品の詳細:
| 起源の場所: | 中国 |
| ブランド名: | Charming |
| 証明: | CE, ROHS, LVD, EMC, CB, BIS, UL |
| モデル番号: | P1.86/P2/P2.5/P3/P3.076/P4 |
お支払配送条件:
| 最小注文数量: | 10個 |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | カートンケース、木製ケース、フライトケース |
| 受渡し時間: | 支払後5営業日 |
| 支払条件: | L/C、T/T、Western Union、PayPal、Cash |
| 供給の能力: | 週に10000個 |
|
詳細情報 |
|||
| リフレッシュレート(Hz): | 3840-7680HZ | グレーレベル: | 14-16ビット |
|---|---|---|---|
| 保護レベル: | IP40 保護レベル | 寿命 (数時間): | ≥30000 |
| 動作電圧: | AC 110/220V, 50/60Hz | 使用湿度: | 10~65%RH |
| 光度 (cd/m2): | 400から800 | スキャンモード (スキャン): | 1/32 |
| モジュール最大電力（W）: | 6-25W | ||
| ハイライト: | adjustable magnet LED display modules,indoor LED modules for flat screens,enhanced visual performance LED displays |
||
製品の説明
Indoor LED Display Modules Featuring Adjustable Magnet Height for Improved Screen Flatness and Enhanced Visual Performance
Product introduce
Product Parameters
|
Module Pixel |
P2 | P2.5 |
P3 |
P3.076 | P4 |
|---|---|---|---|---|---|
|
Dimension(MM) |
320x160mm | 320x160mm |
192x192mm |
256x128mm | 320x160mm |
|
Max Power(W) |
25W | 25W |
13W |
18W | 6W |
|
Scan Mode |
1/40scan | 1/32scan |
1/20scan |
1/26scan | 1/32scan |
|
Refresh Rate(Hz) |
7680Hz | 7680Hz |
1920Hz/3840Hz |
1920Hz/3840Hz | 1920Hz/3840Hz |
|
Pixel Density(Dot/ ㎡)
|
250000 Dot/m²
|
160000 Dot/m²
|
111111Dot/m²
|
105625 Dot/m²
|
62500Dot/m²
|
|
Led Standard |
SMD1515 |
SMD2020
|
SMD2020
|
SMD2020
|
SMD2020
|
|
Brightness(CD/M²) |
700CD/M² |
≥800CD/M² | ≥800CD/M² | ≥700CD/M² | ≥400CD/M² |
|
Viewing Angle |
135° |
||||
|
IP Rate |
IP40 |
||||
|
Life Span
|
≥30000 Hours
|
||||
|
Working Voltage
|
DC 5V
|
||||
|
Grey Level |
14-16 bit |
||||
|
Working Temperature |
20~50℃ |
||||
|
Working Humidity |
10%~65%RH |
||||
|
Maintenance Method
|
Pre maintenance | ||||
|
Working Voltage |
AC110V/220V | ||||
About US
With over 20 years of experience, Charming LED is a trusted leader in digital signs and billboards. Whether you're looking for a single digital LED sign or a complete billboard solution, our expertise helps you make the right choice for your business. Our vibrant, high-quality LED displays and electronic signage solutions are built to capture attention and set you apart from the competition. Don't settle for ordinary — elevate your brand with Charming LED. Call our digital LED sign experts today and see the difference!
What we offer to customer?
Q1. How can I get the price?
A: We typically provide a quote within 24 hours after receiving your inquiry. If you require the price urgently, please email us or contact us via other channels, and we will respond with a quote as soon as possible.
Q2. What's the warranty?
A: We offer a 2-year warranty. We also prepare adequate spare parts for you. If any parts fail, they can be replaced in time without disrupting your operation.
Q3. Can we make any size of LED display?
A: Not exactly. The final size is determined by the LED module and cabinet dimensions. For instance, for a rental outdoor LED display, the smallest unit size is 500mm × 1000mm.
Q4. How to ship?
A: The display can be shipped by air or by sea. We generally recommend sea freight as it is more economical.
