Custom Price Indoor Small Pitch Smd Fixed 640x480 P1.86 Display Video Wall Led Screen on Sale
商品の詳細:
| 起源の場所: | チャイナ。 |
| ブランド名: | Charmingled. |
| 証明: | CE, ROHS, LVD, EMC, CB, BIS, UL. |
| モデル番号: | P1.86 P2 P2.22 P2.5。 |
お支払配送条件:
| 最小注文数量: | 10個のPC。 |
|---|---|
| 価格: | Negotiable. |
| パッケージの詳細: | カートンケース、木製ケース、フライトケース。 |
| 受渡し時間: | 支払い後30営業日。 |
| 支払条件: | L/C、T/T、Western Union、PayPal、Cash |
| 供給の能力: | 1週間あたり100000PCS。 |
|
詳細情報 |
|||
| 寿命。: | ≥50000時間 | グレーレベル。: | 14-16ビット。 |
|---|---|---|---|
| リフレッシュレート（Hz）: | 7680Hz/3840Hz/1920Hz。 | 使用温度: | -20〜50℃。 |
| 使用湿度: | 10％〜90％RH | 動作電圧: | DC 5V。 |
| ハイライト: | P1.86 SMD LED video wall,indoor fixed LED display screen,640x480 small pitch display |
||
製品の説明
Custom Price Indoor Small Pitch SMD Fixed 640x480 P1.86 Display Video Wall LED Screen
Since its founding, Charming Co., Ltd. has been a dedicated pioneer in the entertainment lighting and LED industry, driving technological innovation and delivering exceptional service worldwide. In 2003, we introduced the world's first LED display into the entertainment sector, a breakthrough that cemented our role as a trendsetter.
Today, we are recognized as one of China's most trusted brands in this field. Our commitment is reflected in nearly 100 patents and key international certifications, including ISO9001, CE, and CCC. Operating from a 10,000+ sqm facility equipped with automated production lines, we live by the philosophy of "Charming Achieve Beauty." For over 22 years, we have provided reliable products and services to clients in more than 150 countries and regions.
Technical Specifications
| Parameters | SP2 | SP2.22 | SP2.5 | SP3 | SP4 (256x128) | SP4 (256x256) |
|---|---|---|---|---|---|---|
| Type Number. | SP2. | SP2.22. | SP2.5. | SP3. | SP4. | SP4. |
| Dimension (MM). | 320x160. | 320x160. | 320x160. | 192x192. | 256x128. | 256x256. |
| Pixel Pitch (MM). | 2. | 2.22. | 2.5. | 3. | 4. | 4. |
| LED Standard. | SMD1515. | SMD2020. | SMD2020. | SMD2020. | SMD2020. | SMD2020. |
| Scan Mode. | 1/40 Scan. | 1/36 Scan. | 1/32 Scan. | 1/32 Scan. | 1/32 Scan. | 1/32 Scan. |
| Pixel Density (Dot/m²). | 250000. | 202500. | 160000. | 111111. | 62500. | 62500. |
| Module Max.Power (W). | 22. | 20. | 24. | 10. | 5. | 10. |
| Best Viewing Distance (M). | ≥2.5. | ≥2.5. | ≥2.5. | ≥3. | ≥4. | ≥4. |
| Refresh Rate (Hz). | 7680. | 3840/1920. | 3840/1920. | 3840/1920. | 3840/1920. | 3840/1920. |
| Brightness (CD/m²). | 800. | ≥700. | ≥800. | ≥600. | ≥400. | ≥400. |
| Viewing Angle. | 120°. | 120°. | 120°. | 120°. | 120°. | 120°. |
| Protection Level. | IP42. | IP42. | IP42. | IP42. | IP42. | IP42. |
| Grey Level. | 14-16 bit. | 14-16 bit. | 14-16 bit. | 14-16 bit. | 14-16 bit. | 14-16 bit |
| Working Temperature. | -20 ~ 50℃. | -20 ~ 50℃. | -20 ~ 50℃. | -20 ~ 50℃ | -20 ~ 50℃ | -20 ~ 50℃ |
| Working Humidity. | 10% ~ 90%RH. | 10% ~ 90%RH. | 10% ~ 90%RH. | 10% ~ 90%RH | 10% ~ 90%RH. | 10% ~ 90%RH |
| Life Span. | ≥50000 Hours. | ≥50000 Hours. | ≥50000 Hours. | ≥50000 Hours. | ≥50000 Hours. | ≥50000 Hours |
| Working Voltage. | DC 5V. | DC 5V. | DC 5V. | DC 5V. | DC 5V | DC 5V. |
Warranty & Support
Comprehensive Warranty Coverage
- 2-Year Full Warranty - Free replacement or repair for any defective displays, modules, or parts
- Lifetime Maintenance - Only material costs apply after the warranty period
- Free Technical Training - Includes hands-on operation & maintenance training at our factory
- Comprehensive Documentation - Operation manuals, software, test reports, CAD drawings, and expert guidance provided
After-Sales Service Package
- On-site technical support (available upon request)
- Remote troubleshooting assistance
- Regular system maintenance recommendations
- Software/firmware updates
- Spare parts supply chain support
Frequently Asked Questions
Can I place a sample order for an LED screen?
Yes, we encourage sample orders for both LED modules and full LED screens, so you can evaluate quality and performance firsthand.
What is the delivery time for the goods?
For LED modules, delivery takes 1-5 days. For complete LED screen orders under 100 square meters, we deliver within 15 working days.
What kind of warranty do you provide?
We offer a one-year warranty on all our products.
How is the after-sales service handled?
We have a dedicated after-sales team and a service hotline to promptly respond to your feedback and concerns. We also provide 24/7 online support to assist with any issues.
Can we customize the LED display to any size?
The size of the LED display depends on the dimensions of the LED modules and cabinets used, so fully free-size customization is not available.
How do we install the LED display?
We provide installation drawings and can also offer remote guidance via TeamViewer to assist you during installation.
What information is needed to place an order?
Please let us know the desired display size and its intended use, so we can recommend the best solution.
What shipping methods are available?
We generally ship by air or sea. For cost efficiency, we recommend sea freight, especially for larger orders.
What payment methods are accepted?
We accept T/T, West Union, and Alibaba Trade Assurance. We highly recommend using Alibaba Trade Assurance for a secure transaction.
