詳細情報 |
|||
| タイプ番号: | P2.604 / P2.976 | 寸法 (mm): | 500x500x79MM / 500x1000x79MM |
|---|---|---|---|
| 画素密度: | "147456 dot/m2 / 112896 dot/m2"と書いてある | キャビネット重量 ((kg): | 6.4KG/11KG |
| 保護レベル: | IP65 | 寿命: | ≥50000 時間 |
| 明るさ（CD/m）: | 4500 cd/m2 | 作業温度: | -20~60°C |
| ハイライト: | P2.6 outdoor rental LED display,P2.9 ultra-light LED cabinet,500x1000mm rental LED display |
||
製品の説明
| Attribute | Value |
|---|---|
| Type Number | P2.604 / P2.976 |
| Dimension (MM) | 500x500x79MM / 500x1000x79MM |
| Pixel Density | 147456 dot/m² / 112896dot/m² |
| Cabinet Weight (KG) | 6.4KG / 11KG |
| Protection Level | IP65 |
| Life Span | ≥50000 hours |
| Brightness (CD/m) | 4500 CD/㎡ |
| Working temperature | -20~60°C |
- Strong rigidity - oxidation-resistant and deformation-resistant
- Precise splicing for various shapes
- Each cabinet unit features a 10° curvature (minimum 36 units required for complete cylindrical structure)
- Ultra-lightweight: 6.4kg (500×500mm) and 11kg (500×1000mm)
- Significant weight reduction improves outdoor event suitability and installation efficiency
| Specification | P2.6MM | P2.9MM |
|---|---|---|
| Dimension (mm) | 500x500x79MM | 500x1000x79mm |
| Cabinet Weight | 6.4kg | 11kg |
| Refresh Rate | 7680hz | |
| Pixel Density (Dot/m²) | 147456Dot/m² | 112896Dot/m² |
| Protection Level | IP65 | |
| Scan Mode | 1/24Scan | |
| Cabinet Material | Aluminum Alloy | |
| Maintenance Method | Back Maintenance | |
| Life Span | ≥50000 hours | |
| Working Voltage | AC 110/220V,±15% | |
We guarantee all our displays, modules, and parts for two full years. During this time, we will replace or amend all our goods for free if there is something wrong with them.
- Lifetime maintenance (charges only for raw materials)
- Free technology training including operation and maintenance
- Complete documentation including operation manual, software, test reports
- CAD drawings for display setup and expert suggestions provided
Charming Co., Ltd has always been committed to technical innovation and service of global entertainment lighting & LED. Since 2003, we have led the trend of LED applications in entertainment field.
- First brand of customer satisfaction in China's entertainment lighting LED
- Nearly 100 patents and certifications including ISO9001, CE, CCC, CB, ROHS, SASO
- 10,000+ sqm factory with international standard full-automatic production line
- Serving customers in 150+ countries for 22 years
We accept various shipping terms including EXW, FOB, CFR, CIF, DDU and DDP. Plenty of shipping resources are available to ensure reliable delivery.
Yes, we welcome sample orders to test and check the quality of both the LED module and the LED screen.
It could be shipped by sea, by air, or by express (EMS, UPS, DHL, TNT, FEDEX, etc).
Please tell us the size of LED display and where it will be used.
We have a professional team handling after-sales service, including a service hot-line and 24-hour online support to help solve problems.
